The Effect of Addition of Ground Granulated Blast Furnace Slag (GGBFS) and Cement 2% as Material for the Stabilization of Clay Soil

Introduction

Clay soil, a result of weathering the chemical elements of rock constituents, has a microscopic size to submicroscopic. Although widely used as a construction material, not all clay soils have adequate carrying capacity. Therefore, a soil improvement method is needed, known as stabilization, to improve the quality of clay soils in order to meet the technical requirements of construction. Soil stabilization is done by mixing clay soil with certain materials, so that the physical and mechanical properties of the soil can be improved.

In this study, the effect of adding the addition of ground granulated blast furnace slag (GGBFS) with a mixture and cement variation of 2% in each mixture as a stabilization material. This study aims to assess the increase in the properties of clay soil through testing the California Bearing Ratio (CBR) and free compressive tests. It is hoped that the use of this material can improve the carrying capacity of clay soil to meet the specified technical requirements.

Materials and Methods

The original clay sample had 62.50% moisture content, specific weight 2.59, liquid limit (LL) 60.82%, plastic limit (PL) 24.38%, and Plasticity Index (IP) 36, 44%. Based on the classification, the original clay is included in the Clay High Plasticity (CH) category according to USCS and A-7-6 according to AASHTO. The Non-Unsoided Laboratory CBR value for the original soil reaches 2.52%, while the unconfined compression test value is 1.15 gr/cm².

The addition of GGBFS has a significant effect on improving soil quality. In a mixture with 35% GGBFS and 2% cement, the maximum value of CBR is not submerged at 6.85% and the free compressive strength test value is 2.52 gr/cm² after the affair period of 14 days. This shows that the combination of GGBFS and cement is effective in increasing the carrying capacity of clay soils.

Discussion

Ground Granulated Blast Furnace Slag (GGBFS) is a side product of steel making and has reactive properties when mixed with water and cement. By adding GGBFS, not only provides an increase in strength, but can also reduce the rate of shrinkage and improve soil stability in the long run.

With this stabilization, clay soils that initially have a high plasticity index can be transformed into more stable material and have better resistance to loads. This study emphasizes the importance of choosing the right stabilization material in the process of soil improvement, so as to prevent problems that may arise in the field, such as a decrease in carrying capacity or structural damage.

The Importance of Stabilization

The application of the method of stabilizing clay soil with the use of GGBFS and cement in infrastructure construction can contribute to sustainability, especially in areas that are at risk for soil movement. By improving land quality, infrastructure development can be done more securely and efficiently, minimizing economic losses due to damage caused by unstable land.

Conclusion

From this study, it can be concluded that the addition of ground granulated blast furnace slag and cement 2% play an important role in improving the physical and mechanical properties of clay soils. This is proven by the increase in the value of CBR and free compressive test, making clay soil more feasible to use in construction. By continuing to develop stabilization methods and utilize local materials, it is hoped that the quality of infrastructure in the future can be more guaranteed and sustainable.

Future Research Directions

Further research is needed to explore the potential of GGBFS and cement as a stabilization material for clay soils. This includes investigating the effects of different GGBFS and cement ratios on the physical and mechanical properties of clay soils, as well as the long-term stability of the stabilized soil. Additionally, the use of GGBFS and cement in other types of soils, such as expansive soils, should be explored.

Limitations of the Study

This study has several limitations. Firstly, the study only investigated the effects of GGBFS and cement on clay soils with high plasticity index. Further research is needed to investigate the effects of GGBFS and cement on clay soils with different plasticity indices. Secondly, the study only used a single type of GGBFS and cement, and further research is needed to investigate the effects of different types of GGBFS and cement on clay soils.

Recommendations for Future Research

Based on the findings of this study, the following recommendations are made for future research:

Investigate the effects of different GGBFS and cement ratios on the physical and mechanical properties of clay soils.
Investigate the long-term stability of the stabilized soil.
Explore the use of GGBFS and cement in other types of soils, such as expansive soils.
Investigate the effects of different types of GGBFS and cement on clay soils.

Conclusion

In conclusion, this study has demonstrated the potential of GGBFS and cement as a stabilization material for clay soils. The addition of GGBFS and cement has been shown to improve the physical and mechanical properties of clay soils, making them more feasible to use in construction. Further research is needed to explore the potential of GGBFS and cement as a stabilization material for clay soils, and to investigate the effects of different GGBFS and cement ratios on the physical and mechanical properties of clay soils.
Frequently Asked Questions (FAQs) about the Effect of Addition of Ground Granulated Blast Furnace Slag (GGBFS) and Cement 2% as Material for the Stabilization of Clay Soil

Q: What is Ground Granulated Blast Furnace Slag (GGBFS)?

A: Ground Granulated Blast Furnace Slag (GGBFS) is a side product of steel making and has reactive properties when mixed with water and cement. It is a type of industrial by-product that can be used as a stabilization material for clay soils.

Q: What is the purpose of adding GGBFS to clay soil?

A: The purpose of adding GGBFS to clay soil is to improve its physical and mechanical properties, making it more feasible to use in construction. GGBFS can increase the strength and stability of clay soil, reducing the risk of settlement and structural damage.

Q: What is the effect of adding cement 2% to clay soil?

A: The addition of cement 2% to clay soil can improve its physical and mechanical properties, making it more feasible to use in construction. Cement can increase the strength and stability of clay soil, reducing the risk of settlement and structural damage.

Q: What is the California Bearing Ratio (CBR) test?

A: The California Bearing Ratio (CBR) test is a laboratory test used to determine the bearing capacity of soil. It measures the resistance of soil to penetration by a standard load, providing an indication of its ability to support loads.

Q: What is the free compressive strength test?

A: The free compressive strength test is a laboratory test used to determine the compressive strength of soil. It measures the resistance of soil to compressive forces, providing an indication of its ability to support loads.

Q: What are the benefits of using GGBFS and cement as a stabilization material for clay soil?

A: The benefits of using GGBFS and cement as a stabilization material for clay soil include:

Improved physical and mechanical properties of clay soil
Increased strength and stability of clay soil
Reduced risk of settlement and structural damage
Improved sustainability and environmental benefits

Q: What are the limitations of using GGBFS and cement as a stabilization material for clay soil?

A: The limitations of using GGBFS and cement as a stabilization material for clay soil include:

Limited availability of GGBFS and cement in some regions
High cost of GGBFS and cement in some regions
Potential for environmental impacts associated with the production and use of GGBFS and cement

Q: What are the future research directions for using GGBFS and cement as a stabilization material for clay soil?

A: Future research directions for using GGBFS and cement as a stabilization material for clay soil include:

Investigating the effects of different GGBFS and cement ratios on the physical and mechanical properties of clay soils
Investigating the long-term stability of the stabilized soil
Exploring the use of GGBFS and cement in other types of soils, such as expansive soils
Investigating the effects of different types of GGBFS and cement on clay soils

Q: What are the recommendations for using GGBFS and cement as a stabilization material for clay soil?

A: Recommendations for using GGBFS and cement as a stabilization material for clay soil include:

Conducting thorough site investigations and soil testing to determine the suitability of GGBFS and cement for the specific project
Following established construction practices and guidelines for the use of GGBFS and cement
Monitoring the performance of the stabilized soil over time to ensure its continued stability and integrity.

Q: What are the potential applications of using GGBFS and cement as a stabilization material for clay soil?

A: Potential applications of using GGBFS and cement as a stabilization material for clay soil include:

Infrastructure construction, such as roads and bridges
Building construction, such as foundations and walls
Land reclamation and development
Environmental remediation and restoration.

Q: What are the potential environmental benefits of using GGBFS and cement as a stabilization material for clay soil?

A: Potential environmental benefits of using GGBFS and cement as a stabilization material for clay soil include:

Reduced greenhouse gas emissions associated with the production and use of GGBFS and cement
Improved soil stability and reduced risk of landslides and erosion
Enhanced sustainability and environmental benefits associated with the use of industrial by-products.
