The Importance of Monitoring Electric Voltage

Monitoring electric voltage is crucial for maintaining the safety and efficiency of household appliances. Most electronic devices are designed to operate within a specific voltage range. If the voltage exceeds or falls below this standard, it can cause damage or failure of function. For instance, if a refrigerator operates at a voltage that is too low, its performance will be disrupted, and its lifespan may be shortened. Conversely, if the voltage is too high, it can cause electronic components to burn.

Using an IoT-based monitoring system offers numerous benefits. Users can monitor their hardware remotely, for example, when traveling, they can check the voltage status through applications on their smartphones and ensure everything is functioning properly. Additionally, when an abnormal voltage is detected, users can take preventive action, such as shutting down equipment or notifying technicians.

Monitoring System Components

AC ZMPT101B Sensor

The AC ZMPT101B is a voltage sensor designed to measure AC electricity. This sensor offers high accuracy and can operate in various universal voltages, making it suitable for use in household monitoring systems. By using this sensor, the voltage data measured is sent to the microcontroller for management and further processing.

Nodemcu ESP8266

The Nodemcu ESP8266 is a microcontroller module equipped with Wi-Fi capabilities. This makes it an ideal tool for IoT-based projects due to its ease of connection. After the sensor measures the voltage, the Nodemcu will process the data and send it to the designated server or application. Users can easily access this information through the Android application that has been developed.

Design and Implementation

To design and implement the monitoring system, the following steps were taken:

Sensor Selection: The AC ZMPT101B sensor was selected for its high accuracy and ability to operate in various universal voltages.
Microcontroller Selection: The Nodemcu ESP8266 was chosen for its Wi-Fi capabilities and ease of connection.
Software Development: An Android application was developed to display the voltage data measured by the sensor.
System Integration: The sensor, microcontroller, and Android application were integrated to form the monitoring system.

Benefits of the Monitoring System

The monitoring system offers several benefits, including:

Real-time Voltage Monitoring: Users can monitor the voltage status of their household appliances in real-time.
Remote Monitoring: Users can monitor their hardware remotely, ensuring that everything is functioning properly.
Preventive Action: Users can take preventive action when an abnormal voltage is detected, such as shutting down equipment or notifying technicians.
Increased Safety: The monitoring system provides an additional layer of safety for electronic devices, reducing the risk of damage or failure.

Conclusion

The use of the AC ZMPT101B microcontroller and Nodemcu ESP8266 has made monitoring electric voltage in households much easier and more efficient. This tool not only provides additional security for electronic devices but also increases the comfort for users. Plus, the ability to access data directly through the Android application allows users to stay connected and know the electricity conditions in their homes, anywhere and anytime. The application of IoT technology in voltage monitoring is a good first step towards a smarter and safer household.

Future Work

Future work on this project could include:

Improving Sensor Accuracy: Further research could be conducted to improve the accuracy of the AC ZMPT101B sensor.
Developing a Web Interface: A web interface could be developed to allow users to access the voltage data through a web browser.
Integrating with Other IoT Devices: The monitoring system could be integrated with other IoT devices, such as smart plugs or thermostats, to provide a more comprehensive view of household energy usage.

References

AC ZMPT101B Sensor Datasheet: The datasheet for the AC ZMPT101B sensor provides detailed information on its specifications and operation.
Nodemcu ESP8266 Datasheet: The datasheet for the Nodemcu ESP8266 provides detailed information on its specifications and operation.
Android Application Development: The development of the Android application was based on the Android SDK and API documentation.

Appendix

The following appendix provides additional information on the design and implementation of the monitoring system:

System Diagram: A system diagram is provided to illustrate the components and connections of the monitoring system.
Code Snippets: Code snippets are provided to illustrate the software development process and implementation of the monitoring system.
Test Results: Test results are provided to demonstrate the accuracy and reliability of the monitoring system.
