Understanding the Issue

When it comes to 3D printing, precise control over the extruder and fan is crucial for achieving high-quality prints. However, some users have reported an issue where the printer retracts the filament excessively before changing the fan speed in absolute mode. This can lead to print failures, as the sudden retraction can cause the filament to break or become tangled.

The Role of G-Code in 3D Printing

G-code is a programming language used to control 3D printers. It consists of a series of commands that instruct the printer on how to move, extrude, and retract the filament. In the context of the issue at hand, the G-code is responsible for controlling the fan speed and extruder retraction.

Analyzing the Erroneous G-Code

The provided screenshot of the erroneous G-code reveals a series of commands that appear to be responsible for the excessive retraction. Upon closer inspection, it becomes clear that the issue lies in the way the fan speed is being changed.

M106 S0 ; turn off fan
G1 F3000 X0 Y0 Z0.2 E-1.5 F3000 ; retract filament
M106 S100 ; turn on fan

In this example, the G-code first turns off the fan (M106 S0) and then retracts the filament by 1.5mm (G1 F3000 X0 Y0 Z0.2 E-1.5 F3000). This is followed by turning on the fan (M106 S100). The issue arises when the printer retracts the filament excessively before changing the fan speed.

The Impact of Absolute Mode

Absolute mode is a setting in the printer's firmware that allows for precise control over the extruder and fan. However, when used in conjunction with the erroneous G-code, it can lead to the excessive retraction issue.

The Role of Firmware in 3D Printing

Firmware is the software that controls the printer's hardware. In the case of the Creality Print 6.0.1.1794, the firmware is responsible for executing the G-code and controlling the extruder and fan.

Troubleshooting the Issue

To troubleshoot the issue, it is essential to identify the root cause of the problem. In this case, the erroneous G-code is the primary culprit. To resolve the issue, the G-code needs to be modified to prevent excessive retraction.

Modifying the G-Code

To modify the G-code, the following changes can be made:

M106 S0 ; turn off fan
G1 F3000 X0 Y0 Z0.2 E-0.5 F3000 ; retract filament
M106 S100 ; turn on fan

In this modified version of the G-code, the retraction distance has been reduced from 1.5mm to 0.5mm. This should prevent the excessive retraction and resolve the issue.

Conclusion

In conclusion, the issue of massive retraction before fan speed change in absolute mode is a complex problem that requires a deep understanding of G-code and firmware. By analyzing the erroneous G-code and modifying it to prevent excessive retraction, users can resolve the issue and achieve high-quality prints.
