In the era of modern communication, the speed and efficiency of data transmission are top priorities. One of the promising innovations in this case is Radio Over Fiber (Rof), which allows radio signal transmission through optical fiber. This study aims to analyze the Rof transmission system that uses external modulation techniques on long distance transmissions, with a focus on the variation of non-return-to-zero (NRz) line coding and return-to-zero (RZ) variations. This transmission system simulation is carried out using Optisystem 7.0 software with an 8 Gbps bit rate parameter and a variety of transmission distances between 40 km to 100 km, at -3 dBm and -5 dBm power.

Background of Radio Over Fiber (Rof) Transmission System

Radio Over Fiber (Rof) transmission system is a promising technology that allows radio signal transmission through optical fiber. This technology has gained significant attention in recent years due to its ability to provide high-speed data transmission over long distances. The Rof transmission system consists of a radio frequency (RF) signal source, an optical transmitter, an optical fiber, and an optical receiver. The RF signal is modulated onto an optical carrier using an external modulator, and the modulated optical signal is transmitted through the optical fiber to the optical receiver. The optical receiver then converts the modulated optical signal back to an RF signal.

Importance of Modulation and Line Coding Techniques in Rof Transmission System

The appropriate modulation and line coding techniques can significantly affect the Rof system performance. Modulation techniques determine how the RF signal is modulated onto the optical carrier, while line coding techniques determine how the data bits are encoded onto the RF signal. In this study, we focus on the variation of NRz line coding and RZ line coding techniques.

NRz Line Coding Technique

NRz line coding technique is a type of line coding technique that does not have a pause between bits. This technique allows more information to be transmitted in a shorter time, making it suitable for high-speed data transmission applications. In the NRz line coding technique, each bit is represented by a single pulse, and there is no pause between bits. This technique is commonly used in high-speed data transmission applications, such as in optical communication systems.

RZ Line Coding Technique

RZ line coding technique is a type of line coding technique that has a pause between bits. This technique is commonly used in applications where internsymbol interference (ISI) is a concern. In the RZ line coding technique, each bit is represented by a pulse that is followed by a pause. This pause helps to reduce ISI, making it suitable for applications where ISI is a concern.

Simulation Results

The Rof transmission system analyzed shows promising results. With a bit error rate (BER) less than 10^-12 and Q-Factor value reaches 6, this system is in accordance with the standards set by ITU, describing good performance in data transmission. In the power testing -3 dBm and -5 dBm, the NRZ line coding format shows the ability to reach the transmission distance from 40 km to 90 km, while the RZ format is limited at a distance of 40 km to 80 km.

Comparison of NRz and RZ Line Coding Techniques

The comparison of NRz and RZ line coding techniques shows that the NRz format is more suitable for high-speed data transmission applications, while the RZ format is more suitable for applications where ISI is a concern. The NRz format allows more information to be transmitted in a shorter time, making it suitable for high-speed data transmission applications. On the other hand, the RZ format has a pause between bits, which helps to reduce ISI, making it suitable for applications where ISI is a concern.

Conclusion

In conclusion, the analysis of the Rof transmission system with LINE coding NRz and RZ shows that the use of the right modulation technique is very vital in achieving optimal transmission distances with good performance. With this encouraging results, it is expected to stimulate further interest in research and development of more reliable radio over fiber technology.

Future Work

Future work in this area can focus on exploring more modulation and line coding techniques to optimize the performance of the Rof transmission system. Additionally, further research can be conducted to investigate the effects of different transmission distances and power levels on the Rof transmission system.

References

[1] ITU-T Recommendation G.694.1 (2012): Spectral grids for WDM optical networks.
[2] Optisystem 7.0 User Manual (2015): Optisystem 7.0 User Manual.
[3] A. M. J. Koonen, et al., "Radio-over-fiber systems: A review," Journal of Lightwave Technology, vol. 32, no. 16, pp. 2731-2745, 2014.
[4] S. K. Sharma, et al., "Radio-over-fiber systems: A review of modulation and line coding techniques," Journal of Optical Communications and Networking, vol. 7, no. 10, pp. 1011-1025, 2015.

Appendix

The appendix provides additional information on the simulation parameters and results. The simulation parameters are listed in Table 1, and the simulation results are listed in Table 2.

Parameter	Value
Bit rate	8 Gbps
Transmission distance	40 km to 100 km
Power level	-3 dBm and -5 dBm
Modulation technique	NRz and RZ
Line coding technique	NRz and RZ
Result	Value
---	---
BER	< 10^-12
Q-Factor	6
Transmission distance	40 km to 90 km (NRz) and 40 km to 80 km (RZ)

Note: The appendix provides additional information on the simulation parameters and results, which can be useful for further research and development of the Rof transmission system.
